Lumin X1 Network Music Player

The Lumin X1 is the flagship digital source for listeners who want streaming to feel truly high-end. With dual ES9038PRO DACs, dual-mono fully balanced design, Femto clocking, Lundahl output transformers, optical network isolation, and native DSD512/PCM768 playback, it is engineered to uncover every layer of your music. Add Leedh volume control, Roon Ready support, MQA, TIDAL, Qobuz, AirPlay, and a stunning CNC chassis, and the X1 becomes more than a streamer—it is a statement piece that can make digital playback sound expansive, refined, and emotionally alive.

Technical Specifications:

DSD Support:
Up to DSD512 22.6MHz, 1-bit

PCM Support:
Up to 768kHz, 16–32-bit, Stereo

Analog Output Stage:
Dual ESS SABRE32 ES9038Pro DAC chips
Fully balanced layout with high-quality components
Output connectors coupled with dual LUNDAHL LL7401 output transformers
Femto Clock System with precision FPGA distribution

Upsampling rates & bit depths:
DSD128 upsampling option for all files
PCM 384kHz upsampling option for all files

Digital Output Stage:
USB:
Native DSD512 support
PCM 44.1–768kHz, 16–32-bit, Stereo
BNC SPDIF:
PCM 44.1kHz–192kHz, 16–24-bit
DSD (DoP, DSD over PCM) 2.8MHz, 1-bit

Optical Network:
Industry-standard Gigabit SFP
1000Base-T Gigabit Ethernet
Adapter may be needed for your particular switch/cables
Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)

Power Supply:
External solid billet cnc dual-toroidal
Separate digital & analogue circuitry
Low-noise linear regulator
9-pin Output Connector

Physical:

Finish:
Black anodised aluminium (with matching PSU)
Raw anodised aluminium (with matching PSU)
Lumin (solid aluminium chassis):
350mm (W), 345mm (D), 60mm (H), 8kg
PSU (solid aluminium chassis):
106mm (W), 334mm (D), 60mm (H), 4kg
