Rega - Aphelion 2 - Reference Moving Coil Cartridge

The Rega Aphelion 2 Reference Moving Coil Cartridge is Rega’s flagship low-output moving coil design engineered to deliver uncompromising analog performance for world-class vinyl playback systems. Developed using advanced materials, ultra-low-mass construction techniques, and precision hand-built assembly methods, the Aphelion 2 is designed to maximize musical detail retrieval, transient speed, and tonal accuracy.

Built around a highly optimized moving coil generator architecture, the Aphelion 2 incorporates a boron rod cantilever, fine line nude diamond stylus profile, and an ultra-miniaturized iron micro cross and coil assembly to achieve exceptional groove tracing precision and extremely low moving mass. Rega’s high-power neodymium magnet system and ultra-fine 0.018mm wire construction further enhance speed, transparency, and low-level detail retrieval.

The graded zero-tolerance black anodised aluminium body provides exceptional rigidity and resonance control while maintaining precise alignment integrity. Optimized for use with premium moving coil phono stages, the Aphelion 2 delivers exceptional channel separation, refined tonal balance, and highly accurate musical presentation for reference analog systems.

Available Configurations & Options:
Compatible with adjustable MC phono stages
Lifetime warranty against manufacturer defects

FEATURES

• Reference low-output moving coil cartridge design
• Graded zero tolerance black anodised aluminium body
• Boron rod cantilever
• ‘Fine line’ profile nude diamond stylus
• Iron micro cross and coil assembly
• One of the world’s smallest moving coil generators
• World’s most powerful miniaturised neodymium magnet
• High specification fine wire 0.018mm construction
• Ultra-low-mass moving coil architecture
• Optimized for reference MC phono stages
• Designed for highly accurate groove tracing
• Exceptional low-level detail retrieval
• Low-resonance mechanical construction
• Lifetime warranty against manufacturer defects
• Designed and engineered by Rega

SPECIFICATIONS

Type: Reference Moving Coil Cartridge
Tracking Pressure: 1.9g
Input Load Impedance: 100Ω
Output Impedance: 10Ω
Nominal Output Voltage: 350μV
Channel Balance: ≥ 10μV
Separation: ≥ -29dB
Mass: 6g
Recommended Load Impedance: 100Ω
Recommended Capacitance: 1000pF
Recommended Gain Setting: High (“On” position for Rega phono stages)
