Vertere - RG-1 Reference Groove - Turntable

The Vertere RG-1 Reference Groove Turntable is Vertere’s flagship reference record player engineered to recreate the live music experience with uncompromising precision, ultra-low noise performance, and extraordinary musical realism. Designed as the company’s ultimate statement in analog playback engineering, the RG-1 combines advanced mechanical design, precision machining, and highly sophisticated motor control technologies to extract the maximum amount of information from the vinyl groove.

Every element of the RG-1 has been meticulously optimized to minimize resonance, maintain absolute rotational stability, and preserve delicate musical information. From its aerospace-grade bearing assembly and articulated synchronous motor system to its dual-layer damped platter architecture and advanced reference motor drive electronics, the RG-1 delivers true reference-grade analog performance for the world’s finest vinyl playback systems.

MAIN BEARING ASSEMBLY

At the heart of the RG-1 is an ultra-high precision main bearing assembly engineered to provide exceptionally smooth and silent platter rotation. This advanced design minimizes unwanted bearing noise and mechanical interference, ensuring the record is presented to the tonearm and cartridge with maximum stability and accuracy.

TURNTABLE MOTOR

The RG-1 utilizes a sophisticated 24-pole synchronous motor assembly mounted within a proprietary articulated aluminium alloy housing. Precision bearings maintain continuous synchronous operation and constant belt tension, allowing the platter to rotate at highly stable speeds with minimal interference and vibration.

MAIN REFERENCE PLATTER

The platter assembly features a unique two-piece super precision machined aluminium alloy construction designed to provide friction-only damping characteristics. The precisely matched interface between the main platter and platter insert forms a linearly damped, non-resonant structure engineered for exceptional rotational stability and resonance control.

PLATTER UNDERSIDE

The underside of the main platter is precision machined for a highly accurate fit to the spindle block while maximizing peripheral mass distribution. This design improves inertia-to-weight ratio, enhancing speed consistency while minimizing stress on the main bearing assembly for optimal long-term performance and longevity.

PLATTER INSERT

The platter insert incorporates a bonded 2mm cast acrylic record interface disc and is engineered to mate precisely with the main platter surface. Six stainless steel fasteners secure the assembly into a highly stable non-resonant structure, optimizing energy dissipation and playback accuracy.

RG-1 REFERENCE MOTOR DRIVE

The RG-1 Reference Motor Drive utilizes Vertere’s most advanced motor control circuitry to achieve maximum performance and precise speed stability. Seven selectable fine speed adjustment settings allow highly accurate speed trimming from ±0.25% to ±3.00% around both 33rpm and 45rpm operation. The advanced drive system minimizes noise and distortion while delivering exceptionally smooth platter drive characteristics.

SG-1 MK III MOTOR DRIVE

The SG-1 Mk III Motor Drive incorporates enhanced circuitry for improved speed accuracy and power delivery. Fully protected output devices provide smoother and more stable motor drive performance while maintaining elegant and intuitive operation.

RG-1 DUST COVER

An optional fully enclosing dust cover is available for the RG-1, constructed from clear cast acrylic panels designed to complement the elegant lines of the turntable. The integrated design incorporates dedicated cut-outs for tonearm and motor drive cabling while maintaining structural rigidity and aesthetic refinement.

SPECIAL METALLIC FINISHES

The RG-1 is available in a selection of premium special metallic finishes developed specifically to preserve the acoustic integrity of the clear cast acrylic plinth structure. Advanced printing methods allow the application of Metallic Black, Pearlescent White, and Champagne finishes while maintaining the reference-level performance characteristics of the platform.

PACKAGE INCLUDES

Ref. Bearing/Platter/Tempo Motor Drive & Cable

TECHNICAL SPECIFICATIONS

Type: Belt Drive Turntable
Motor: 24 Pole Synchronous
Motor Support: 6 Point Body Contact Support
Spindle Support: Acetal Ball Bearing
Motor Mount: Acetal Platform – Articulated
Motor Bearings: 2 Ball Race Bearings and Silicone Motor Spring
Pulley: Super Precision Aluminium Alloy
Drive Belt: Precision Ground Polymer
Platter: Super Precision Aluminium Alloy
Platter Design: Two Part Linear Damped Construction
Record Interface: 2mm Bonded Acrylic Record Interface
Bearing Spindle: Super Precision Tungsten Carbide
Bearing Finish Tolerance: < 1 Micron Roundness / Concentricity
Bearing Housing: Aerospace Grade Phosphor Bronze
Bearing Clearance: < 4 Microns
Plinth Structure: Clear Cast Acrylic with Optional Metallic Finishes
Available Finishes: Metallic Black, Metallic Pearlescent White, Metallic Champagne
Plinth Thickness: 30mm Top and Bottom Plinths
Sub-Plinth Thickness: 20mm
Mid-Plinth Thickness: 15mm
Isolation System: 3 Stage Compliant and 2 Stage Rigid
Isolation Components: 12 Decoupler Sets and 12 Tuned Silicone Ring / Bobbins
Feet Construction: 3mm Acrylic Disc and Stainless Feet / Hard Rubber / Felt
Motor Drive Power Supply: Precision Crystal Referenced
Selectable Speeds: 33.3rpm and 45rpm (<0.2%)
Wow and Flutter: <0.1%
Rumble: <-85dB
