Sumiko - Oriole - Low Output Moving Coil Cartridge

The Sumiko Oriole is a premium low output moving coil cartridge that delivers remarkable musicality, refinement, and realism. Positioned just below the acclaimed Starling, the Oriole combines a high-efficiency, low-impedance generator with a nude Shibata stylus to reveal extraordinary detail, expansive soundstaging, and captivating dynamics while maintaining the smooth, natural character Sumiko is renowned for.

Its open-body Reference Series architecture minimizes unwanted resonance through a precision PEEK generator mounting plate and rigid alloy headblock, allowing music to emerge from an exceptionally quiet background with outstanding transparency and lifelike imaging. The result is a richly textured presentation that balances precision with warmth, making every recording feel immersive and emotionally engaging.

Handcrafted in Yokohama, Japan by the skilled artisans at Excel Sound, the Oriole represents an exceptional step into true reference-level moving coil performance for discerning vinyl enthusiasts.

FEATURES

• Reference Series low output moving coil (MC) cartridge
• Nude Shibata stylus (6.5 × 40 μm)
• Reinforced 0.5 mm aluminum pipe cantilever
• Open-body architecture for reduced resonance and coloration
• PEEK generator mounting plate for superior mechanical stability
• High-efficiency, low-impedance moving coil generator
• High-purity copper coils
• Outstanding detail retrieval, imaging, and transient response
• Handcrafted in Yokohama, Japan
• Eligible for Sumiko Re-Tip Exchange program (U.S. only)

SPECIFICATIONS

• Type: Low Output Moving Coil (MC)
• Stylus: Nude Shibata (6.5 × 40 μm)
• Cantilever: 0.5 mm Reinforced Aluminum Pipe
• Coils: High-Purity Copper
• Output Voltage: 0.3 mV (3.54 cm/sec @ 1 kHz)
• Frequency Response: 12 Hz – 45 kHz
• Channel Separation: 30 dB @ 1 kHz
• Channel Balance: <0.5 dB @ 1 kHz
• Internal Impedance: 5.5 Ω
• Recommended Load Impedance: >55 Ω (optimize by ear)
• Recommended Capacitance: 100–200 pF
• Compliance: 12 × 10⁻⁶ cm/dyn @ 100 Hz
• Vertical Tracking Angle: 20°
• Tracking Force Range: 1.8–2.2 g
• Recommended Tracking Force: 2.0 g
• Weight: 7.3 g
• Replacement Program: Sumiko Re-Tip Exchange (Dealer Program)
• Handcrafted In: Japan
